| 產品特性 : | 多款供選 | 品牌 : | 耀達五金 |
| 型號 : | 松不脫螺絲PF21_PF22 | 類別 : | 不脫出螺釘 |
| 頭型 : | 圓頭 | 槽型 : | 多款供選 |
| 作用方式 : | 壓鉚 | 螺紋規格 : | M2-M10 #4#6 |
| 螺紋公差 : | 6g | 公稱長度 : | 10.5（mm） |
| 表面處理 : | 鍍鋅。鍍鎳。鍍鉻。鈍化，發黑，氧化等 | 材料等級 : | 鋁 碳鋼 不銹鋼 銅 |
| 產品等級 : | A級 | 標準類型 : | 國標 |
| 標準編號 : | 標準件 | 加工定制 : | 是 |
| 產品規格 : | M3-M8 |
| PF21類PF22類壓鉚式松不脫螺絲PRESS-IN STYLS PANEL FASTENER ASSEMBLIES PF21 PF22 | ||||
| PF21-M3-12.3 | PF21-M3-14 | PF21-M3-15.5 | PF21-M3-17.1 | |
| PF21-M3.5-16.4 | PF21-M3.5-18 | PF21-M3.5-19.6 | PF21-M3.5-21.2 | |
| PF21-M4-16.9 | PF21-M4-18.5 | PF21-M4-20 | PF21-M4-21.6 | |
| PF21-M5-16.9 | PF21-M5-18.5 | PF21-M5-20 | PF21-M5-21.6 | |
| PF21-M6-20.5 | PF21-M6-22.1 | PF21-M6-23.7 | PF21-M6-25.3 | |
| PF21-440-12.3 | PF21-440-14 | PF21-440-15.5 | PF21-440-17.1 | |
| PF21-632-16.4 | PF21-632-18 | PF21-632-19.6 | PF21-632-21.2 | |
| PF21-832-16.9 | PF21-832-18.5 | PF21-832-20 | PF21-832-21.6 | |
| PF21-032-16.9 | PF21-032-18.5 | PF21-032-20 | PF21-032-21.6 | |
| PF22-M3.5-16.4 | PF22-M3.5-18 | PF22-M4-20 | PF22-M3.5-21.2 | |
| PF22-M4-16.9 | PF22-M4-18.5 | PF22-M5-20 | PF22-M4-21.6 | |
| PF22-M5-16.9 | PF22-M5-18.5 | PF22-M6-23.7 | PF22-M5-21.6 | |
| PF22-M6-20.5 | PF22-M6-22.1 | PF22-440-15.5 | PF22-M6-25.3 | |
| PF22-440-12.3 | PF22-440-14 | PF22-632-19.6 | PF22-440-17.1 | |
| PF22-632-16.4 | PF22-632-18 | PF22-832-20 | PF22-632-21.2 | |
| PF22-832-16.9 | PF22-832-18.5 | PF22-032-20 | PF22-832-21.6 | |
| PF22-032-16.9 | PF22-032-18.5 | PF22-0420-23.7 | PF22-032-21.6 | |
| PF22-0420-20.5 | PF22-0420-22.1 | PF22-0420-25.3 | ||
